Mounts and canvas options

This reference documents every current public declaration in this part of Pine. Examples run inside App.Mount(), a component factory, or an explicit P.Root(...) unless they only create state/configuration. Explicit P.Mount(...) remains available for advanced ownership. Variable names such as count, items and label refer to the typed values described by each example. All APIs run on Unity’s main thread.

CanvasOptions​

CanvasOptions

Typed reactive configuration for a Pine-owned canvas.

CanvasOptions.Persistent​

bool Persistent

Whether a Pine-owned canvas survives scene changes.

CanvasOptions.Name​

Value<string> Name

Reactive name for a Pine-owned canvas; defaults to Canvas.

CanvasOptions.ReferenceResolution​

Value<Vector2> ReferenceResolution

Reactive positive reference resolution for native canvas scaling; defaults to 1920 by 1080 with a 0.5 width/height match.

CanvasOptions.SortOrder​

Value<int> SortOrder

Reactive native Canvas sorting order; defaults to 100.

CanvasOptions.RenderMode​

Value<RenderMode> RenderMode

Reactive rendering mode: overlay by default, camera or world-space when explicitly selected.

CanvasOptions.Camera​

Value<Camera> Camera

Reactive native camera reference.

CanvasOptions.Scale​

Value<float> Scale

Reactive positive UI scale multiplier; it adjusts reference scaling for screen canvases and local transform scale for world canvases.

CanvasOptions.SafeArea​

Value<bool> SafeArea

Reactive opt-in safe-area handling for the Pine-owned screen-space surface.

CanvasOptions.WorldPosition​

Value<Vector3> WorldPosition

Reactive world canvas position, applied in WorldSpace mode.

CanvasOptions.WorldRotation​

Value<Quaternion> WorldRotation

Reactive world canvas rotation, applied in WorldSpace mode.

CanvasOptions.WorldSize​

Value<Vector2> WorldSize

Reactive finite non-negative world canvas dimensions before its scale multiplier.

P.DefaultFont​

TMP_FontAsset DefaultFont

Configures Pine's code-supplied default TMP font for subsequent text construction.

P.Mount​

public static Mount Mount(
    Func<Component> component,
    Transform parent = null,
    CanvasOptions options = null
)

An explicit mounted interface lifetime.

public static Mount Mount(
    Func<GameObject> component,
    Transform parent = null,
    CanvasOptions options = null
)

An explicit mounted interface lifetime.

UnitySpringSpaces​

UnitySpringSpaces

Built-in spring mappings for Unity vectors, colors, rectangles, quaternions and poses.

UnitySpringSpaces.Vector2​

SpringSpace<Vector2> Vector2

Built-in fixed-lane mapping for Vector2.

UnitySpringSpaces.Vector3​

SpringSpace<Vector3> Vector3

Built-in fixed-lane mapping for Vector3.

UnitySpringSpaces.Vector4​

SpringSpace<Vector4> Vector4

Built-in fixed-lane mapping for Vector4.

UnitySpringSpaces.Color​

SpringSpace<Color> Color

Built-in fixed-lane mapping for Color.

UnitySpringSpaces.Rect​

SpringSpace<Rect> Rect

Built-in fixed-lane mapping for Rect.

UnitySpringSpaces.Quaternion​

SpringSpace<Quaternion> Quaternion

Built-in fixed-lane mapping for Quaternion.

UnitySpringSpaces.Pose​

SpringSpace<Pose> Pose

Built-in fixed-lane mapping for Pose.
