Native declarations and bindings

This reference documents every current public declaration in this part of Pine. Examples run inside App.Mount(), a component factory, or an explicit P.Root(...) unless they only create state/configuration. Explicit P.Mount(...) remains available for advanced ownership. Variable names such as count, items and label refer to the typed values described by each example. All APIs run on Unity’s main thread.

IProperty

IProperty<in T>

A contravariant declaration operation restricted to compatible native component types.

IProperty.Apply

void Apply(T target)

Applies this compatible property to the supplied native target in the current ownership scope.

GraphicProperty

GraphicProperty

A color binding shared by native Graphics and Selectables.

GraphicProperty.Identity

string Identity

The named native operation used by strict duplicate diagnostics.

Mount

Mount

An explicit mounted interface lifetime.

Mount.Scope

Scope Scope

The scope owning this mounted interface, including bindings and native objects.

Mount.Root

GameObject Root

The native root returned by the mount builder.

Mount.Canvas

Canvas Canvas

The Pine-created canvas or nearest ancestor canvas of an explicit parent.

Mount.Dispose

public void Dispose()

Ends this owned lifetime idempotently.

P.Cleanup

public static void Cleanup(UnityEngine.Object target)

Registers a callback, disposable or Unity object with the active scope.

P.Create

public static T Create<T>(params IProperty<T>[] properties)
    where T : Component

Creates and owns a GameObject, RectTransform and the native component T, then applies compatible typed properties.

P.Clone

public static T Clone<T>(T template, params IProperty<T>[] properties)
    where T : Component

Owns a native clone of the supplied component's GameObject, preserves its serialized native configuration, and applies compatible properties.

P.Apply

public static T Apply<T>(T target, params IProperty<T>[] properties)
    where T : Component

Applies compatible declarations to an existing native component in the active scope.

P.Group

public static IProperty<T> Group<T>(params IProperty<T>[] properties)
    where T : Component

Composes reusable properties for one explicit native target type.

P.Action

public static IProperty<T> Action<T>(Action<T> action, int priority = 1)
    where T : Component

Runs a one-time typed action before ordinary properties and parenting.

P.Configure

public static IProperty<T> Configure<T>(Action<T> configure)
    where T : Component

Runs a one-time typed native configuration in the ordinary-property phase.

P.Set

public static IProperty<T> Set<T, TValue>(
    string name,
    Action<T, TValue> set,
    Value<TValue> value
)
    where T : Component

Declares a named typed native assignment.

public static IProperty<T> Set<T, TValue>(string name, Action<T, TValue> set, Func<TValue> read)
    where T : Component

Declares a named typed native assignment.

P.Bind

public static T Bind<T, TValue>(this T component, Func<TValue> read, Action<T, TValue> apply)
    where T : Component

Adds an owned reactive getter/setter binding to a saved native component and returns the same component.

P.Name

public static IProperty<Component> Name(Value<string> name)

Binds the native GameObject name.

public static IProperty<Component> Name(Func<string> name)

Binds the native GameObject name.

P.Active

public static IProperty<Component> Active(Value<bool> active)

Binds GameObject activeSelf; disabling a native object does not dispose its construction scope.

public static IProperty<Component> Active(Func<bool> active)

Binds GameObject activeSelf; disabling a native object does not dispose its construction scope.

P.Parent

public static IProperty<Component> Parent(Value<Transform> parent)

Binds the native parent Transform while preserving local UI transforms.

public static IProperty<Component> Parent(Func<Transform> parent)

Binds the native parent Transform while preserving local UI transforms.

P.Children

public static IProperty<Component> Children(params Component[] children)

Composes native child components explicitly.

public static IProperty<Component> Children(Func<IEnumerable<Component>> read)

Composes native child components explicitly.

public static IProperty<Component> Children(Func<IEnumerable<GameObject>> read)

Composes native child components explicitly.

P.On

public static IProperty<T> On<T>(Func<T, UnityEvent> select, Action action)
    where T : Component

Registers a native UnityEvent handler for the compatible target type and removes it when the scope ends.

public static IProperty<T> On<T, TValue>(
    Func<T, UnityEvent<TValue>> select,
    Action<TValue> action
)
    where T : Component

Registers a native UnityEvent handler for the compatible target type and removes it when the scope ends.

P.OnClick

public static IProperty<Button> OnClick(Action action)

Registers an owned Button click handler.

P.Changed

public static IProperty<T> Changed<T, TValue>(
    Func<T, TValue> read,
    Action<TValue> changed,
    Func<T, UnityEvent<TValue>> events = null,
    IEqualityComparer<TValue> comparer = null
)
    where T : Component

Observes a native value, calls the callback initially, and reports distinct changes under the supplied comparer.

P.ToggleValue

public static IProperty<Toggle> ToggleValue(Source<bool> source)

Installs a two-way binding between Source<bool> and native Toggle.isOn.

P.SliderValue

public static IProperty<Slider> SliderValue(Source<float> source)

Installs a two-way slider binding and normalizes the source to the native slider's clamped/rounded value.

P.InputValue

public static IProperty<TMP_InputField> InputValue(Source<string> source)

Installs a two-way binding between a string source and TMP_InputField.text.

P.TextProperty

public static IProperty<TMP_Text> TextProperty(Value<string> text)

Binds TMP text while retaining the existing text component.

public static IProperty<TMP_Text> TextProperty(Func<string> text)

Binds TMP text while retaining the existing text component.

P.FontSize

public static IProperty<TMP_Text> FontSize(Value<float> size)

Binds TMP font size in canvas units.

public static IProperty<TMP_Text> FontSize(Func<float> size)

Binds TMP font size in canvas units.

P.Font

public static IProperty<TMP_Text> Font(Value<TMP_FontAsset> font)

Binds a code-supplied TMP font asset; null resolves the Pine default/fallback.

public static IProperty<TMP_Text> Font(Func<TMP_FontAsset> font)

Binds a code-supplied TMP font asset; null resolves the Pine default/fallback.

P.Tint

public static GraphicProperty Tint(Value<Color> color)

Binds Graphic.color or a Selectable targetGraphic color through a compile-safe shared property.

public static GraphicProperty Tint(Func<Color> color)

Binds Graphic.color or a Selectable targetGraphic color through a compile-safe shared property.

P.Enabled

public static IProperty<Selectable> Enabled(Value<bool> enabled)

Binds Selectable.interactable; disabled controls retain their native objects and bindings.

public static IProperty<Selectable> Enabled(Func<bool> enabled)

Binds Selectable.interactable; disabled controls retain their native objects and bindings.

P.Navigation

public static IProperty<Selectable> Navigation(Value<Navigation> navigation)

Binds the native Selectable navigation configuration, including explicit directional links.

public static IProperty<Selectable> Navigation(Func<Navigation> navigation)

Binds the native Selectable navigation configuration, including explicit directional links.

P.Focus

public static IProperty<Selectable> Focus()

Selects the native control through the active EventSystem; native navigation maintains visible focus states.

P.Opacity

public static IProperty<Component> Opacity(Value<float> opacity)

Adds or reuses CanvasGroup and binds alpha clamped to the range zero through one.

public static IProperty<Component> Opacity(Func<float> opacity)

Adds or reuses CanvasGroup and binds alpha clamped to the range zero through one.

P.Sprite

public static IProperty<Image> Sprite(Value<Sprite> sprite)

Binds the sprite of a native Image.

public static IProperty<Image> Sprite(Func<Sprite> sprite)

Binds the sprite of a native Image.

P.Texture

public static IProperty<RawImage> Texture(Value<Texture> texture)

Binds the texture of a native RawImage.

public static IProperty<RawImage> Texture(Func<Texture> texture)

Binds the texture of a native RawImage.
