Springs and custom value spaces

This reference documents every current public declaration in this part of Pine. Examples run inside App.Mount(), a component factory, or an explicit P.Root(...) unless they only create state/configuration. Explicit P.Mount(...) remains available for advanced ownership. Variable names such as count, items and label refer to the typed values described by each example. All APIs run on Unity’s main thread.

SpringSpace​

SpringSpace<T>

A typed mapping between a custom value and a fixed number of finite double lanes.

SpringSpace.Pack​

Func<T, double[]> Pack

Maps the typed value into a fixed number of finite double lanes.

SpringSpace.Unpack​

Func<double[], T> Unpack

Reconstructs the typed value from the fixed lane order produced by Pack.

SpringSpace.SpringSpace​

public SpringSpace(Func<T, double[]> pack, Func<double[], T> unpack)

Constructs this value with the supplied typed arguments.

SpringSpaces​

SpringSpaces

Built-in lane mappings for scalar floats, doubles and fixed-length double arrays.

SpringSpaces.Float​

SpringSpace<float> Float

Built-in fixed-lane mapping for Float.

SpringSpaces.Double​

SpringSpace<double> Double

Built-in fixed-lane mapping for Double.

SpringSpaces.Array​

SpringSpace<double[]> Array

Built-in fixed-lane mapping for Array.

P.Spring​

public static Spring<T> Spring<T>(
    Func<T> target,
    Value<double>? period = null,
    Value<double>? dampingRatio = null,
    SpringSpace<T> space = null
)

An owned reactive analytic spring whose output moves toward a tracked target.

Spring​

Spring<T>

An owned reactive analytic spring whose output moves toward a tracked target.

Spring.Value​

T Value

Reads reactive spring output.

Spring.Control​

public void Control(
    Value<T>? position = null,
    Value<T>? velocity = null,
    Value<T>? impulse = null
)

Sets position and/or velocity and adds an impulse using the spring's fixed typed space.

Spring.Dispose​

public void Dispose()

Ends this owned lifetime idempotently.
